MIC4479YM-TR
IC GATE DRVR LOW-SIDE 8SOICManufacturer: Microchip Technology
Categories: Gate Drivers
Quality Control: Learn More
The Microchip Technology MIC4479YM-TR is a dual, low-side N-channel MOSFET gate driver. This inverting gate driver features independent channels with a peak output current capability of 2.5A source and 2.5A sink, enabling efficient switching of power MOSFETs. It operates with a supply voltage range of 4.5V to 32V and exhibits typical rise and fall times of 120ns and 45ns respectively. The device is housed in an 8-SOIC surface mount package and is supplied on tape and reel. This component is suitable for applications in industrial control systems and power supply designs.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Voltage - Supply | 4.5V ~ 32V |
| Input Type | Inverting |
| Supplier Device Package | 8-SOIC |
| Rise / Fall Time (Typ) | 120ns, 45ns |
| Channel Type | Independent |
| Driven Configuration | Low-Side |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V |
| Current - Peak Output (Source, Sink) | 2.5A, 2.5A |
| Programmable | Not Verified |
