MIC4423BWM
LOW-SIDE MOSFET DRIVERManufacturer: Microchip Technology
Categories: Gate Drivers
Quality Control: Learn More
The Microchip Technology MIC4423BWM is a dual, low-side MOSFET driver IC. This device features inverting inputs and is packaged in a 16-SOIC for surface mount applications. Each driver in the MIC4423BWM is capable of delivering a peak output current of 3A source and 3A sink, supporting both N-channel and P-channel MOSFET gate types. The device operates from a supply voltage range of 4.5V to 18V, with typical rise and fall times of 28ns and 32ns respectively. The logic voltage thresholds for VIH and VIL are 2.4V and 0.8V. This component is designed for applications requiring efficient switching of power MOSFETs, commonly found in power supply control, motor drive, and industrial automation systems. The operating temperature range is -40°C to 150°C (TJ).
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 16-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Voltage - Supply | 4.5V ~ 18V |
| Input Type | Inverting |
| Supplier Device Package | 16-SOIC |
| Rise / Fall Time (Typ) | 28ns, 32ns |
| Channel Type | Independent |
| Driven Configuration | Low-Side |
| Number of Drivers | 2 |
| Gate Type | N-Channel, P-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V |
| Current - Peak Output (Source, Sink) | 3A, 3A |
| Programmable | Not Verified |
