ATA6836C-TIQY
IC HALF BRIDGE DRIVER 28SOManufacturer: Microchip Technology
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Microchip Technology's ATA6836C-TIQY is a high-side/low-side driver designed for controlling inductive, capacitive, and resistive loads. This half-bridge driver, packaged in a 28-SOIC (0.295", 7.50mm Width), offers robust fault protection including open load detection, over-temperature, short circuit, and undervoltage lockout (UVLO). It features an SPI interface for communication and provides a status flag. With a peak output current of 650mA and a load voltage range of 5.5V to 40V, the ATA6836C-TIQY is suitable for applications such as controlling bulbs, DC motors, and resistors. The supply voltage range is 4.75V to 5.25V. This device operates within a temperature range of -40°C to 150°C (TJ). The ATA6836C-TIQY is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Status Flag |
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Interface | SPI |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (6) |
| Voltage - Supply | 4.75V ~ 5.25V |
| Rds On (Typ) | 1Ohm LS, 1Ohm HS |
| Applications | Bulbs, DC Motors, Resistors |
| Current - Output / Channel | - |
| Current - Peak Output | 650mA |
| Technology | Power MOSFET |
| Voltage - Load | 5.5V ~ 40V |
| Supplier Device Package | 28-SO |
| Fault Protection | Open Load Detect, Over Temperature, Short Circuit, UVLO |
| Load Type | Inductive, Capacitive, Resistive |
