M1020-PQ100C
Field Programmable Gate Array, 2000 Gates, 125MHz, PQFP100Manufacturer: Microchip Technology
Categories: Field Programmable Gate Arrays
Quality Control: Learn More
The Microchip Technology M1020 series Field Programmable Gate Array (FPGA) offers a robust solution for logic implementation. This component, part number M1020-PQ100C, features 2000 equivalent gates and operates at a maximum clock frequency of 125 MHz. It is housed in a 100-terminal PQFP (Plastic Quad Flat Pack) package with a 0.65 mm terminal pitch, suitable for surface mounting. The device supports a supply voltage range of 4.75V to 5.25V. Applications span industrial automation, consumer electronics, and telecommunications. The combinatorial delay of a CLB is a maximum of 1.5 ns. The operating temperature range is 0°C to 70°C.
Additional Information
Series: M1020RoHS Status: Manufacturer Lead Time: Product Status: Active-UnconfirmedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Width | 14.0000 |
| Length | 20.0000 |
| Clock_Frequency_Max | 125.00000 |
| Combinatorial_Delay_of_a_CLB_Max | 1.5000000000000000 |
| JESD_30_Code | R-PQFP-G100 |
| Number_of_Equivalent_Gates | 2000 |
| Number_of_Inputs | 69 |
| Number_of_Outputs | 69 |
| Number_of_Terminals | 100 |
| Operating_Temperature_Max | 70.0 |
| Operating_Temperature_Min | 0.0 |
| Organization | 2000 GATES |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | QFP |
| Package_Shape | Rectangular |
| Package_Style | FlatPack |
| Programmable_Logic_Type | FIELD PROGRAMMABLE GATE ARRAY |
| Seated_Height_Max | 3.4000 |
| Supply_Voltage_Max | 5.25000 |
| Supply_Voltage_Min | 4.75000 |
| Supply_Voltage_Nom | 5 |
| Surface_Mount | Yes |
| Terminal_Form | Gull Wing |
| Terminal_Pitch | 0.650 |
| Terminal_Position | QUAD |
