APTM50HM75FTG
MOSFET 4N-CH 500V 46A SP4Manufacturer: Microchip Technology
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Microchip Technology APTM50HM75FTG. This 4 N-Channel MOSFET array features a maximum drain-source voltage of 500V and a continuous drain current of 46A at 25°C. The device offers a low on-resistance of 90mOhm at 23A and 10V, with a maximum power dissipation of 357W. Key parameters include a gate charge of 123nC at 10V and an input capacitance of 5600pF at 25V. The APTM50HM75FTG utilizes MOSFET technology and is supplied in a Chassis Mount SP4 package for efficient thermal management. This component is suitable for applications in power factor correction, motor control, and uninterruptible power supplies.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 31 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | SP4 |
| Mounting Type | Chassis Mount |
| Configuration | 4 N-Channel (Full Bridge) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 357W |
| Drain to Source Voltage (Vdss) | 500V |
| Current - Continuous Drain (Id) @ 25°C | 46A |
| Input Capacitance (Ciss) (Max) @ Vds | 5600pF @ 25V |
| Rds On (Max) @ Id, Vgs | 90mOhm @ 23A, 10V |
| Gate Charge (Qg) (Max) @ Vgs | 123nC @ 10V |
| FET Feature | - |
| Vgs(th) (Max) @ Id | 5V @ 2.5mA |
| Supplier Device Package | SP4 |
