5962-8852506YX
EEPROM, 32KX8, 150ns, Parallel, CMOS, CQCC32Manufacturer: Microchip Technology
Categories: EEPROMs
Quality Control: Learn More
Microchip Technology's 5962-8852506YX is a 262,144-bit CMOS Parallel EEPROM. This component features a memory organization of 32K words by 8 bits, providing 32,768 words of non-volatile data storage. The access time is rated at a maximum of 150 ns, suitable for applications requiring rapid data retrieval. Operating within a temperature range of -55°C to +125°C, this device is designed for demanding environments. The EEPROM utilizes a 5V programming voltage and operates from a 4.5V to 5.5V supply. Its parallel interface simplifies integration into existing system architectures. Encased in a 32-terminal Ceramic Quad Flat Pack (CQFP) package, identified by the R-CQCC-N32 standard, it offers robust thermal and electrical performance. This component is utilized in aerospace, defense, and industrial control systems where reliability and data integrity are paramount. The write cycle time is a maximum of 10 ms.
Additional Information
Series: 5962-8852506RoHS Status: Manufacturer Lead Time: Product Status: DiscontinuedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Length | 13.9700 |
| Width | 11.4300 |
| Technology | CMOS |
| Access_Time_Max | 150.0000000000000000 |
| JESD_30_Code | R-CQCC-N32 |
| Memory_Density | 262144.0000000000000000 |
| Memory_IC_Type | EEPROM |
| Memory_Organization | 32KX8 |
| Memory_Width | 8 |
| Number_of_Functions | 1 |
| Number_of_Terminals | 32 |
| Number_of_Words | 32768.0000000000000000 |
| Number_of_Words_Code | 32k |
| Operating_Mode | Asynchronous |
| Operating_Temperature_Max | 125.0 |
| Operating_Temperature_Min | -55.0 |
| Package_Body_Material | CERAMIC, METAL-SEALED COFIRED |
| Package_Code | QCCN |
| Package_Shape | Rectangular |
| Package_Style | CHIP CARRIER |
| Parallel_Serial | Parallel |
| Programming_Voltage | 5 |
| Screening_Level_Reference_Standard | MIL-STD-883 Class C |
| Seated_Height_Max | 2.5400 |
| Supply_Voltage_Max | 5.50000 |
| Supply_Voltage_Min | 4.50000 |
| Supply_Voltage_Nom | 5 |
| Surface_Mount | Yes |
| Terminal_Form | NO LEAD |
| Terminal_Pitch | 1.270 |
| Terminal_Position | QUAD |
| Write_Cycle_Time_Max_tWC | 10.0000000000000000 |
