JANS1N7043CAT1
DIODE ARR SCHOTT 100V 35A TO254Manufacturer: Microchip Technology
Categories: Diode Arrays
Quality Control: Learn More
Microchip Technology JANS1N7043CAT1 is a Schottky diode array featuring a common anode configuration with a maximum reverse voltage of 100V. Each diode in the array is rated for an average rectified current of 35A, with a forward voltage drop of 1.3V at 35A. Reverse leakage is specified at 500 µA at 100V. This component is housed in a TO-254-3, TO-254AA through-hole package, operating across a junction temperature range of -65°C to 150°C. Qualified to MIL-PRF-19500/730, this device is suitable for high-reliability applications, including aerospace and defense systems. The Schottky technology ensures fast switching characteristics.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-254-3, TO-254AA |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Diode Configuration | 1 Pair Common Anode |
| Current - Average Rectified (Io) (per Diode) | 35A |
| Supplier Device Package | TO-254 |
| Operating Temperature - Junction | -65°C ~ 150°C |
| Grade | Military |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 1.3 V @ 35 A |
| Current - Reverse Leakage @ Vr | 500 µA @ 100 V |
| Qualification | MIL-PRF-19500/730 |
