1N6642UBD
DIODE ARRAY GP 75V 300MA UBManufacturer: Microchip Technology
Categories: Diode Arrays
Quality Control: Learn More
The Microchip Technology 1N6642UBD is a dual diode array featuring a series connection configuration. This general-purpose diode array offers a maximum DC reverse voltage of 75V and an average rectified current per diode of 300mA. Designed for surface mounting, it utilizes a 4-SMD, No Lead package (UB) and operates within a junction temperature range of -65°C to 175°C. The device exhibits a typical forward voltage of 1.2V at 100mA and a reverse leakage of 500 nA at 75V. With a fast recovery time of 5 ns, this component is suitable for applications in industrial and automotive sectors.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: 35 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 4-SMD, No Lead |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 5 ns |
| Technology | Standard |
| Diode Configuration | 1 Pair Series Connection |
| Current - Average Rectified (Io) (per Diode) | 300mA |
| Supplier Device Package | UB |
| Operating Temperature - Junction | -65°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 75 V |
| Voltage - Forward (Vf) (Max) @ If | 1.2 V @ 100 mA |
| Current - Reverse Leakage @ Vr | 500 nA @ 75 V |
