SY605JC
IC DELAY LINE 255TAP PROG 28PLCCManufacturer: Microchip Technology
Categories: Delay Lines
Quality Control: Learn More
Microchip Technology SY605JC is a 255-tap programmable delay line IC housed in a 28-PLCC package. This component offers a total delay range of 4ns to 40ns, with a delay to the first tap at 4ns and a tap increment of 15.7 ps. Designed for surface mount applications, it operates within a voltage supply range of 4.2V to 5.7V and has an operating temperature range of 0°C to 85°C. The SY605JC is utilized in applications requiring precise, digitally controlled signal timing, commonly found in telecommunications, data acquisition systems, and high-speed digital signal processing. Its 255 discrete tap points allow for granular adjustment of signal propagation delay.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 28-LCC (J-Lead) |
| Mounting Type | Surface Mount |
| Function | Programmable |
| Operating Temperature | 0°C ~ 85°C |
| Voltage - Supply | 4.2V ~ 5.7V |
| Number of Taps/Steps | 255 |
| Delay to 1st Tap | 4ns |
| Number of Independent Delays | 1 |
| Available Total Delays | 4ns ~ 40ns |
| Tap Increment | 15.7 ps |
| Supplier Device Package | 28-PLCC (11.48x11.48) |
