SY604JC-TR
IC DELAY LINE 255TAP PROG 28PLCCManufacturer: Microchip Technology
Categories: Delay Lines
Quality Control: Learn More
Microchip Technology SY604JC-TR is a programmable delay line IC featuring 255 taps, offering a total delay range from 4ns to 40ns with a tap increment of 15.7 ps. This surface mount component, supplied in a 28-PLCC package, operates within a 4.2V to 5.7V supply voltage range and a temperature range of 0°C to 85°C. The device is ideal for applications requiring precise signal manipulation, including telecommunications, high-speed digital systems, and test and measurement equipment. Its single, independently controllable delay line with a delay to the first tap of 4ns allows for fine-tuning of signal timing. The SY604JC-TR is delivered on tape and reel for automated assembly processes.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-LCC (J-Lead) |
| Mounting Type | Surface Mount |
| Function | Programmable |
| Operating Temperature | 0°C ~ 85°C |
| Voltage - Supply | 4.2V ~ 5.7V |
| Number of Taps/Steps | 255 |
| Delay to 1st Tap | 4ns |
| Number of Independent Delays | 1 |
| Available Total Delays | 4ns ~ 40ns |
| Tap Increment | 15.7 ps |
| Supplier Device Package | 28-PLCC (11.48x11.48) |
