SY10E195JZ
IC DELAY LINE 128TAP PROG 28PLCCManufacturer: Microchip Technology
Categories: Delay Lines
Quality Control: Learn More
The Microchip Technology SY10E195JZ is a 128-tap programmable delay line from the 10E, Precision Edge® series. This electronic component offers a total delay range from 1.39ns to 3.63ns, with the delay to the first tap at 1.39ns and a tap increment of 20 ps. The device operates with a supply voltage between -4.2V and -5.5V and is specified for an industrial operating temperature range of -40°C to 85°C. Packaged in a 28-PLCC (J-Lead) format for surface mounting, this digitally controlled delay line is suitable for applications in telecommunications, high-speed digital systems, and data communications.
Additional Information
Series: 10E, Precision Edge®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 28-LCC (J-Lead) |
| Mounting Type | Surface Mount |
| Function | Programmable |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | -4.2V ~ -5.5V |
| Number of Taps/Steps | 128 |
| Delay to 1st Tap | 1.39ns |
| Number of Independent Delays | 1 |
| Available Total Delays | 1.39ns ~ 3.63ns |
| Tap Increment | 20 ps |
| Supplier Device Package | 28-PLCC (11.48x11.48) |
