TC7660SMJA
IC REG CHG PUMP INV 20MA 8CERDIPManufacturer: Microchip Technology
Categories: DC DC Switching Regulators
Quality Control: Learn More
Microchip Technology's TC7660SMJA is a charge pump switching regulator IC designed for efficient voltage conversion. This device provides a fixed output voltage that is either negative or positive relative to the input, specifically -Vin or 2Vin. With a single output configuration capable of delivering up to 20mA, the TC7660SMJA operates with an input voltage range from 1.5V to 12V. Its switching frequency spans 10kHz to 45kHz, and it features a ratiometric function. The component is housed in an 8-CERDIP package, suitable for through-hole mounting. This charge pump regulator finds application in various industries, including industrial automation and consumer electronics, where precise voltage regulation is critical. The operating temperature range is -55°C to 125°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-CDIP (0.300"", 7.62mm) |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Function | Ratiometric |
| Current - Output | 20mA |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Output Configuration | Positive or Negative |
| Frequency - Switching | 10kHz ~ 45kHz |
| Voltage - Input (Max) | 12V |
| Topology | Charge Pump |
| Supplier Device Package | 8-CERDIP |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 1.5V |
| Voltage - Output (Min/Fixed) | -Vin, 2Vin |
