TC1222ECHTR
IC REG CHG PUMP INV 25MA SOT23Manufacturer: Microchip Technology
Categories: DC DC Switching Regulators
Quality Control: Learn More
Microchip Technology's TC1222ECHTR is a charge pump switching regulator IC designed for efficient voltage conversion. This single-output device generates a fixed negative output voltage from a positive input, or a doubled positive output, with a maximum output current of 25mA. Operating with an input voltage range of 1.8V to 5.5V, it features a high switching frequency of 750kHz, facilitating the use of smaller external components. The TC1222ECHTR is housed in a compact SOT-23-6 package, suitable for surface mount applications. Its ratiometric function and non-synchronous rectifier design make it a robust solution for power management in various applications including portable electronics and industrial control systems. The operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-6 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Ratiometric |
| Current - Output | 25mA |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive or Negative |
| Frequency - Switching | 750kHz |
| Voltage - Input (Max) | 5.5V |
| Topology | Charge Pump |
| Supplier Device Package | SOT-23-6 |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 1.8V |
| Voltage - Output (Min/Fixed) | -Vin, 2Vin |
