MIC33164YGJ-T5
IC REG BUCK ADJ 1A 20QFNManufacturer: Microchip Technology
Categories: DC DC Switching Regulators
Quality Control: Learn More
Microchip Technology's MIC33164YGJ-T5 is a HyperLight Load® series buck switching regulator. This device provides an adjustable positive output from 0.7V up to 5V with a maximum output current of 1A. Featuring a 4MHz switching frequency, it is designed for efficient step-down conversion. The MIC33164YGJ-T5 incorporates a synchronous rectifier for improved efficiency. It operates within an input voltage range of 2.7V to 5.5V and is specified for an ambient temperature range of -40°C to 125°C. The component is housed in a 20-PowerTFQFN package and is supplied on tape and reel. This regulator is suitable for various applications including portable electronics and power management systems.
Additional Information
Series: HyperLight Load®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-PowerTFQFN |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 1A |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 4MHz |
| Voltage - Input (Max) | 5.5V |
| Topology | Buck |
| Supplier Device Package | 20-QFN (2.5x3) |
| Synchronous Rectifier | Yes |
| Voltage - Output (Max) | 5V |
| Voltage - Input (Min) | 2.7V |
| Voltage - Output (Min/Fixed) | 0.7V |
