MIC3172BN
IC REG MULT CONFIG 1.25A 8DIPManufacturer: Microchip Technology
Categories: DC DC Switching Regulators
Quality Control: Learn More
The Microchip Technology MIC3172BN is a versatile switching regulator IC. This component supports multiple DC-DC converter topologies including Buck, Boost, Cuk, Flyback, and Forward converters, offering flexibility in power design. It can be configured for positive or negative voltage outputs and delivers a maximum output current of 1.25A. Operating at a switching frequency of 100kHz, the MIC3172BN is suitable for applications requiring efficient voltage conversion. The device accepts input voltages ranging from 3V to 40V and is housed in an 8-pin DIP (0.300", 7.62mm) package, facilitating through-hole mounting. This IC finds application in various industrial and consumer electronics sectors.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Output Type | - |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Function | Step-Up, Step-Down, Step-Up/Step-Down |
| Current - Output | 1.25A |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive or Negative |
| Frequency - Switching | 100kHz |
| Voltage - Input (Max) | 40V |
| Topology | Buck, Boost, Cuk, Flyback, Forward Converter |
| Supplier Device Package | 8-PDIP |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 3V |
| Voltage - Output (Min/Fixed) | - |
