MIC24051YJL-TR
IC REG BUCK ADJ 6A 28QFNManufacturer: Microchip Technology
Categories: DC DC Switching Regulators
Quality Control: Learn More
The Microchip Technology MIC24051YJL-TR is a high-performance, adjustable output, synchronous buck switching regulator from the Hyper Speed Control®, SuperSwitcher II™ series. This device is designed for efficient power conversion, delivering up to 6A of output current. It operates with an input voltage range of 4.5V to 19V and offers an adjustable output voltage from 0.8V up to 5.5V. The regulator features a fixed switching frequency of 600kHz, contributing to its compact footprint and excellent transient response. Its synchronous rectification topology enhances efficiency. The MIC24051YJL-TR is housed in a 28-pin QFN (5x6) package, suitable for surface mounting. This component is widely utilized in applications such as high-performance computing, telecommunications infrastructure, and industrial automation systems. The product is supplied in a tape and reel (TR) package for automated assembly.
Additional Information
Series: Hyper Speed Control®, SuperSwitcher II™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-PowerVQFN |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 6A |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 600kHz |
| Voltage - Input (Max) | 19V |
| Topology | Buck |
| Supplier Device Package | 28-QFN (5x6) |
| Synchronous Rectifier | Yes |
| Voltage - Output (Max) | 5.5V |
| Voltage - Input (Min) | 4.5V |
| Voltage - Output (Min/Fixed) | 0.8V |
