MIC2288BML-TR
IC REG BOOST ADJ 1.2A 8MLFManufacturer: Microchip Technology
Categories: DC DC Switching Regulators
Quality Control: Learn More
The Microchip Technology MIC2288BML-TR is an adjustable positive output boost switching regulator. This device is designed for efficient step-up voltage conversion, capable of sourcing up to 1.2A from its internal switch. It operates with an input voltage range of 2.5V to 10V and can generate output voltages up to 34V. Featuring a fixed switching frequency of 1.2MHz, this regulator is suitable for applications demanding high power density and effective thermal management. The MIC2288BML-TR is packaged in an 8-MLF™ (2x2) surface-mount format, supplied on tape and reel. Its robust design makes it applicable in various industrial and consumer electronics sectors requiring reliable power conversion.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-VFDFN Exposed Pad, 8-MLF® |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Up |
| Current - Output | 1.2A (Switch) |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 1.2MHz |
| Voltage - Input (Max) | 10V |
| Topology | Boost |
| Supplier Device Package | 8-MLF™ (2x2) |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | 34V (Switch) |
| Voltage - Input (Min) | 2.5V |
| Voltage - Output (Min/Fixed) | 2.5V |
