MCP16323T-250E/NG
IC REG BUCK 2.5V 3A 16QFNManufacturer: Microchip Technology
Categories: DC DC Switching Regulators
Quality Control: Learn More
Microchip Technology's MCP16323T-250E-NG is a high-performance, synchronous buck switching regulator designed for efficient power conversion. This device provides a fixed 2.5V output with a 3A maximum output current, operating with a 1MHz switching frequency. Its step-down topology and synchronous rectification ensure optimal efficiency across a wide input voltage range of 6V to 18V. The MCP16323T-250E-NG is housed in a compact 16-VFQFN exposed pad package (3x3) suitable for surface mount applications. It is engineered for demanding applications across various industries, including automotive, industrial, and consumer electronics, where reliable and efficient power delivery is critical. The operating temperature range is -40°C to 125°C (TJ).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-VFQFN Exposed Pad |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 3A |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 1MHz |
| Voltage - Input (Max) | 18V |
| Topology | Buck |
| Supplier Device Package | 16-QFN (3x3) |
| Synchronous Rectifier | Yes |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 6V |
| Voltage - Output (Min/Fixed) | 2.5V |
