MIC38HC45-1BM-TR
IC REG CTRLR MULT TOP 14SOICManufacturer: Microchip Technology
Categories: DC DC Switching Controllers
Quality Control: Learn More
The Microchip Technology MIC38HC45-1BM-TR is a versatile DC-DC switching controller designed for a range of power conversion topologies including Buck, Boost, Flyback, and Forward converters. This device features a single positive output with isolation capability, suitable for applications requiring step-up, step-down, or step-up/step-down voltage regulation. It operates with a supply voltage range of 7.6V to 20V and offers frequency control for precise switching management. The MIC38HC45-1BM-TR is configured for a single output phase and drives a transistor. Its 14-SOIC surface mount package, supplied on tape and reel, is ideal for automated assembly processes. This component is commonly utilized in industrial and consumer electronics power management systems.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up, Step-Down, Step-Up/Step-Down |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive, Isolation Capable |
| Frequency - Switching | - |
| Topology | Buck, Boost, Flyback, Forward Converter |
| Voltage - Supply (Vcc/Vdd) | 7.6V ~ 20V |
| Supplier Device Package | 14-SOIC |
| Synchronous Rectifier | Yes |
| Control Features | Frequency Control |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 50% |
| Clock Sync | No |
| Number of Outputs | 1 |
