MIC38C43ABM-TR
IC REG CTRLR MULT TOPOLOGY 8SOICManufacturer: Microchip Technology
Categories: DC DC Switching Controllers
Quality Control: Learn More
The Microchip Technology MIC38C43ABM-TR is a versatile DC-DC controller IC designed for multi-topology applications. This device supports Buck, Boost, Flyback, and Forward converter topologies, enabling step-up, step-down, and step-up/step-down voltage regulation. It features a single positive output capable of isolation and is configured as a transistor driver. With a maximum duty cycle of 96% and a switching frequency of up to 500kHz, it offers efficient power conversion. The operating voltage range is 7.6V to 20V, with an operating temperature range of -40°C to 85°C. This component is suitable for applications in industrial, automotive, and consumer electronics where flexible power supply designs are required. The MIC38C43ABM-TR is supplied in an 8-SOIC surface mount package on tape and reel.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up, Step-Down, Step-Up/Step-Down |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive, Isolation Capable |
| Frequency - Switching | 500kHz |
| Topology | Buck, Boost, Flyback, Forward Converter |
| Voltage - Supply (Vcc/Vdd) | 7.6V ~ 20V |
| Supplier Device Package | 8-SOIC |
| Synchronous Rectifier | Yes |
| Control Features | Frequency Control |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 96% |
| Clock Sync | No |
| Number of Outputs | 1 |
