MCP16502TAE-E/S8B
PMIC FOR SAMA5DX/SAM9X6 MPUSManufacturer: Microchip Technology
Categories: DC DC Switching Controllers
Quality Control: Learn More
Buck Regulator Positive Output Step-Down I2C DC-DC Controller IC 32-VQFN (5x5)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 4 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-VFQFN Exposed Pad |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Down |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 2MHz |
| Topology | Buck |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Supplier Device Package | 32-VQFN (5x5) |
| Synchronous Rectifier | No |
| Control Features | Current Limit, Enable |
| Serial Interfaces | I2C |
| Output Phases | 4 |
| Duty Cycle (Max) | 100% |
| Clock Sync | No |
| Number of Outputs | 4 |
