ATF750LVC-15PC
IC CPLD 10MC 15NS 24DIPManufacturer: Microchip Technology
Categories: CPLDs (Complex Programmable Logic Devices)
Quality Control: Learn More
Microchip Technology ATF750LVC series CPLD, part number ATF750LVC-15PC. This 10 macrocell device offers a 15 ns propagation delay, making it suitable for high-speed logic implementations. Featuring 10 configurable I/O pins, it operates within a voltage range of 3V to 5.25V and is housed in a 24-pin DIP package for through-hole mounting. The EE PLD architecture ensures non-volatile configuration. This component finds application in industrial automation, consumer electronics, and telecommunications infrastructure. Packaged in tubes, it operates within a temperature range of 0°C to 70°C.
Additional Information
Series: ATF750LVCRoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Programmable Type | EE PLD |
| Number of Macrocells | 10 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Delay Time tpd(1) Max | 15 ns |
| Supplier Device Package | 24-PDIP |
| Voltage Supply - Internal | 3V ~ 5.25V |
| Number of I/O | 10 |
| Programmable | Not Verified |
