ATF2500C-20JC
IC CPLD 24MC 20NS 44PLCCManufacturer: Microchip Technology
Categories: CPLDs (Complex Programmable Logic Devices)
Quality Control: Learn More
The Microchip Technology ATF2500C-20JC is a 24 macrocell CPLD from the ATF2500C(L) series, featuring a propagation delay of 20 ns. This in-system programmable device offers 24 I/O pins and operates from a single 4.75V to 5.25V supply. Packaged in a 44-PLCC format, the ATF2500C-20JC is designed for surface mount applications and supports a commercial operating temperature range of 0°C to 70°C. Its robust architecture makes it suitable for applications in industrial control, telecommunications, and consumer electronics.
Additional Information
Series: ATF2500C(L)RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 44-LCC (J-Lead) |
| Mounting Type | Surface Mount |
| Programmable Type | In System Programmable |
| Number of Macrocells | 24 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Delay Time tpd(1) Max | 20 ns |
| Supplier Device Package | 44-PLCC (16.6x16.6) |
| Voltage Supply - Internal | 4.75V ~ 5.25V |
| Grade | - |
| Number of I/O | 24 |
| Programmable | Verified |
| Qualification | - |
