MIC6270BM5-TR
IC COMPARATOR 1 GEN PUR SOT23-5Manufacturer: Microchip Technology
Categories: Comparators
Quality Control: Learn More
Microchip Technology's MIC6270BM5-TR is a single-element, general-purpose comparator featuring a wide operating voltage range of 2V to 36V (single) and ±1V to ±18V (dual). This CMOS device offers multiple output types including CMOS, DTL, ECL, MOS, Open-Collector, and TTL, ensuring broad compatibility with various logic families. With a maximum input bias current of 0.25µA at 5V and a typical output current of 20mA at 5V, it is suitable for applications requiring precise signal comparison. The SC-74A, SOT-753 package (SOT-23-5) facilitates efficient surface mounting. Operating within a temperature range of -40°C to 85°C, this IttyBitty® series component finds application in industrial control, automotive systems, and consumer electronics.
Additional Information
Series: IttyBitty®RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74A, SOT-753 |
| Output Type | CMOS, DTL, ECL, MOS, Open-Collector, TTL |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Single/Dual (±) | 2V ~ 36V, ±1V ~ 18V |
| Supplier Device Package | SOT-23-5 |
| Propagation Delay (Max) | - |
| Current - Quiescent (Max) | 1.2mA |
| Voltage - Input Offset (Max) | 5mV @ 5V |
| Current - Input Bias (Max) | 0.25µA @ 5V |
| Current - Output (Typ) | 20mA @ 5V |
| CMRR, PSRR (Typ) | - |
| Hysteresis | - |
