PL680-37OC
IC CLK BUFFER LVPECL 16TSSOPManufacturer: Microchip Technology
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
Microchip Technology PL680-37OC is a high-performance clock buffer designed for demanding applications. This single-circuit device operates up to 640MHz, offering versatile clock distribution capabilities. It features LVPECL inputs and LVCMOS/LVDS outputs, supporting both division and multiplication functions with a 1:1 input-to-output ratio. The PL680-37OC is housed in a compact 16-TSSOP (0.173", 4.40mm width) surface-mount package. This component is well-suited for use in telecommunications, networking equipment, and high-speed computing systems where precise clock management is critical. It operates across a voltage range of 2.25V to 3.63V and is specified for commercial operating temperatures from 0°C to 70°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Output | LVCMOS, LVDS |
| Frequency - Max | 640MHz |
| Input | Crystal |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 2.25V ~ 3.63V |
| Ratio - Input:Output | 1:1 |
| Differential - Input:Output | No/Yes |
| Supplier Device Package | 16-TSSOP |
| PLL | Yes |
| Divider/Multiplier | Yes/Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
