PL123S-09SC
IC CLK MULTPLX 1:9 134MHZ 16SOICManufacturer: Microchip Technology
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
The Microchip Technology PL123S-09SC is a high-performance clock multiplier with a 1:9 ratio, capable of operating at frequencies up to 134MHz. This device is designed for precision clock generation and distribution in demanding applications. Featuring a single clock input and nine clock outputs, it provides flexible clock management solutions. The PL123S-09SC integrates a Phase-Locked Loop (PLL) with bypass functionality, allowing for direct clock pass-through when needed. Housed in a 16-SOIC (0.154", 3.90mm Width) surface-mount package, it is suitable for automated assembly processes. The component operates within a voltage range of 3V to 3.6V and has an operating temperature range of 0°C to 70°C, making it appropriate for various industrial and commercial environments including telecommunications and consumer electronics.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Output | Clock |
| Frequency - Max | 134MHz |
| Input | Clock |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 3V ~ 3.6V |
| Ratio - Input:Output | 1:9 |
| Differential - Input:Output | No/No |
| Supplier Device Package | 16-SOIC |
| PLL | Yes with Bypass |
| Divider/Multiplier | No/No |
| Number of Circuits | 1 |
| Programmable | Not Verified |
