PL130-07SI-R
IC CLK BUFFER 1:1 200MHZ 8SOPManufacturer: Microchip Technology
Categories: Clock Buffers, Drivers
Quality Control: Learn More
Microchip Technology PL130-07SI-R is a 1:1 clock buffer/driver designed for high-frequency signal distribution. This buffer supports a maximum frequency of 200 MHz and accepts LVCMOS or sine wave inputs. It provides a single LVCMOS output, maintaining signal integrity with its 1:1 ratio. The device operates from a 2.5V to 3.3V supply voltage, making it suitable for a wide array of applications. Packaged in an 8-SOP (Small Outline Package) with a width of 3.90mm, it is designed for surface mounting and is supplied on tape and reel. This component finds application in networking, telecommunications, and consumer electronics where precise clock signal management is critical. The operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Number of Circuits | 1 |
| Mounting Type | Surface Mount |
| Output | LVCMOS |
| Type | Buffer/Driver |
| Input | LVCMOS, Sine Wave |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.5V ~ 3.3V |
| Ratio - Input:Output | 1:1 |
| Differential - Input:Output | No/No |
| Supplier Device Package | 8-SOP |
| Frequency - Max | 200 MHz |
