695-4
BRIDGESManufacturer: Microchip Technology
Categories: Bridge Rectifiers
Quality Control: Learn More
Microchip Technology's 695-4 is a three-phase bridge rectifier designed for robust power rectification in demanding applications. Featuring a standard recovery technology, this component offers an average rectified forward current (Io) of 15 A and a maximum reverse leakage current of 5 µA at 400 V. The forward voltage drop (Vf) is a maximum of 1.2 V at 2 A, ensuring efficient power conversion. With a peak reverse voltage rating of 400 V, it is suitable for applications operating under significant voltage stress.
The 695-4 is engineered for chassis mounting, facilitating integrated thermal management in power supply units, motor control systems, and industrial automation equipment. Its operating temperature range spans from -65°C to 150°C (TJ), providing reliability in diverse environmental conditions. Packaged in bulk, this rectifier is a foundational component for high-power rectification circuits where durability and performance are paramount.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | NC |
| Mounting Type | Chassis Mount |
| Diode Type | Three Phase |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Technology | Standard |
| Supplier Device Package | NC |
| Voltage - Peak Reverse (Max) | 400 V |
| Current - Average Rectified (Io) | 15 A |
| Voltage - Forward (Vf) (Max) @ If | 1.2 V @ 2 A |
| Current - Reverse Leakage @ Vr | 5 µA @ 400 V |
