SG2803L-DESC

DRIVER - MEDIUM CURRENT ARRAY, H

Manufacturer: Microchip Technology

Categories: Bipolar Transistor Arrays

Quality Control: Learn More

Bipolar (BJT) Transistor Array 8 NPN Darlington 50V 500mA Surface Mount 20-CLCC (8.89x8.89)

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TrayDatasheet:
Technical Details:
PackagingTray
Package / Case20-CLCC
Mounting TypeSurface Mount
Transistor Type8 NPN Darlington
Operating Temperature-55°C ~ 125°C (TA)
Power - Max-
Current - Collector (Ic) (Max)500mA
Voltage - Collector Emitter Breakdown (Max)50V
Vce Saturation (Max) @ Ib, Ic1.6V @ 500µA, 350mA
Current - Collector Cutoff (Max)-
DC Current Gain (hFE) (Min) @ Ic, Vce-
Frequency - Transition-
Supplier Device Package20-CLCC (8.89x8.89)
