ZL30415GGG2
IC PLL SONET/SDH CLK MULT 64CBGAManufacturer: Microchip Technology
Categories: Application Specific Clock/Timing
Quality Control: Learn More
The Microchip Technology ZL30415GGG2 is a high-performance SONET/SDH clock multiplier IC. This electronic component, housed in a 64-CSPBGA (8x8) package, offers a maximum output frequency of 622.08MHz. It supports a variety of input signal types including CML, CMOS, LVDS, and LVPECL, with differential input and output capabilities. The ZL30415GGG2 features a 3:2 input-to-output ratio and a sophisticated Phase-Locked Loop (PLL) for precise clock generation. Designed for surface mount applications, this device operates within a voltage range of 3V to 3.6V and an industrial temperature range of -40°C to 85°C. Its primary function is in SONET/SDH network synchronization, making it suitable for telecommunications infrastructure and high-speed data transmission systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 64-LFBGA |
| Mounting Type | Surface Mount |
| Output | CMOS, LVPECL |
| Frequency - Max | 622.08MHz |
| Input | CML, CMOS, LVDS, LVPECL |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3V ~ 3.6V |
| Main Purpose | SONET/SDH |
| Ratio - Input:Output | 3:2 |
| Differential - Input:Output | Yes/Yes |
| Supplier Device Package | 64-CSPBGA (8x8) |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
