ZL30130GGG
IC SONET/SDH SYNCH 100LFBGAManufacturer: Microchip Technology
Categories: Application Specific Clock/Timing
Quality Control: Learn More
Microchip Technology ZL30130GGG is a high-performance clock generation and distribution IC designed for demanding synchronization applications. This device offers precise clocking capabilities up to 622.08MHz, supporting both Ethernet and SONET/SDH network synchronization requirements, as well as Stratum level synchronization. Featuring a single circuit, the ZL30130GGG provides flexible clock output options including LVCMOS and LVPECL. The input interface accepts LVCMOS signals, with an input to output ratio of 13:12. Packaged in a compact 100-CABGA (9x9) and designed for surface mount installation, this component operates within a temperature range of -40°C to 85°C and requires a supply voltage between 2.97V and 3.63V. Its robust design makes it suitable for telecommunications infrastructure, carrier-grade networking, and other precision timing systems.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 100-FBGA |
| Mounting Type | Surface Mount |
| Output | LVCMOS, LVPECL |
| Frequency - Max | 622.08MHz |
| Input | LVCMOS |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.97V ~ 3.63V |
| Main Purpose | Ethernet, SONET/SDH, Stratum |
| Ratio - Input:Output | 13:12 |
| Differential - Input:Output | No/Yes |
| Supplier Device Package | 100-CABGA (9x9) |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
