SY87700LHI
IC CLK DATA REC SDH 175MBPSManufacturer: Microchip Technology
Categories: Application Specific Clock/Timing
Quality Control: Learn More
Microchip Technology's SY87700LHI is an AnyRate® Clock and Data Recovery (CDR) IC designed for high-speed serial data applications up to 175Mbps. This 32-TQFP-EP packaged component offers robust clock and data recovery with PECL and TTL input compatibility, and PECL output. Featuring an integrated PLL and a 3:3 input-to-output ratio, the SY87700LHI is ideal for demanding telecommunications infrastructure, including Ethernet, SONET/SDH, and ATM systems. Its surface mount configuration and -40°C to 85°C operating temperature range ensure reliable performance in various environmental conditions.
Additional Information
Series: AnyRate®RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 32-TQFP Exposed Pad |
| Mounting Type | Surface Mount |
| Output | PECL |
| Frequency - Max | 175Mbps |
| Input | PECL, TTL |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3.15V ~ 3.45V |
| Main Purpose | Ethernet, SONET/SDH, ATM applications |
| Ratio - Input:Output | 3:3 |
| Differential - Input:Output | Yes/Yes |
| Supplier Device Package | 32-TQFP-EP (7x7) |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
