SM802108UMG
IC SYNTEHSIZER 156.25MHZ 24QFNManufacturer: Microchip Technology
Categories: Application Specific Clock/Timing
Quality Control: Learn More
Ethernet Clock/Frequency Synthesizer, Multiplexer IC 156.25MHz 1 Output 24-QFN-EP (4x4)
Additional Information
Series: ClockWorks™, RotaryWave™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Output | LVPECL |
| Frequency - Max | 156.25MHz |
| Input | LVCMOS, Crystal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.375V ~ 3.465V |
| Main Purpose | Ethernet |
| Ratio - Input:Output | 2:4 |
| Differential - Input:Output | No/Yes |
| Supplier Device Package | 24-QFN-EP (4x4) |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
