MAX3624AETJ2T
IC CLOCK GENERATOR PREC 32TQFNManufacturer: Microchip Technology
Categories: Application Specific Clock/Timing
Quality Control: Learn More
Microchip Technology's MAX3624AETJ2T is a precision clock generator and fanout buffer featuring a PLL for precise timing control. This component is designed to support Ethernet and SONET/SDH applications, providing a robust clock distribution solution. It accepts LVCMOS, LVTTL, and crystal inputs, generating LVCMOS and LVPECL outputs. The device operates with a maximum frequency of 318.5MHz and offers a flexible 2:4 input-to-output ratio. Packaged in a 32-TQFN (5x5) with an exposed pad, it is suitable for surface mount applications. The operating temperature range is -40°C to 85°C, and it requires a supply voltage between 3V and 3.6V. This component is supplied on tape and reel (TR).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Output | LVCMOS, LVPECL |
| Frequency - Max | 318.5MHz |
| Input | LVCMOS, LVTTL, Crystal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3V ~ 3.6V |
| Main Purpose | Ethernet, SONET/SDH |
| Ratio - Input:Output | 2:4 |
| Differential - Input:Output | No/Yes |
| Supplier Device Package | 32-TQFN (5x5) |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
