MCP9802A5T-M/OTG

SENSOR DIGITAL -55C-125C SOT23-5

Manufacturer: Microchip Technology

Categories: Analog and Digital Output

Quality Control: Learn More

The Microchip Technology MCP9802A5T-M-OTG is a local digital temperature sensor with a configurable resolution up to 11 bits, enabling precise temperature monitoring within the -55°C to 125°C range. This device features an I2C/SMBus output for efficient data communication and offers programmable limit and shutdown modes for power management. Its accuracy is specified as ±1°C under typical conditions (-10°C to 85°C), with a maximum of ±3°C across its full operating range. The MCP9802A5T-M-OTG includes one-shot conversion and an output switch functionality. Supplied in a SOT-23-5 package, this component is suitable for surface mounting and is delivered on tape and reel. Applications include battery-powered systems, consumer electronics, and industrial control. The operating voltage range is 2.7V to 5.5V.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:
Technical Details:
FeaturesOne-Shot, Output Switch, Programmable Limit, Programmable Resolution, Shutdown Mode
PackagingTape & Reel (TR)
Package / CaseSC-74A, SOT-753
Output TypeI2C/SMBus
Mounting TypeSurface Mount
Operating Temperature-55°C ~ 125°C
Voltage - Supply2.7V ~ 5.5V
Sensor TypeDigital, Local
Resolution11 b
Supplier Device PackageSOT-23-5
Test Condition-10°C ~ 85°C (-55°C ~ 125°C)
Accuracy - Highest (Lowest)±1°C (±3°C)
Sensing Temperature - Local-55°C ~ 125°C
Sensing Temperature - Remote-
