AT30TS750-SS8-T
SENSOR DIGITAL -55C-125C 8SOICManufacturer: Microchip Technology
Categories: Analog and Digital Output
Quality Control: Learn More
Microchip Technology AT30TS750-SS8-T is a digital local temperature sensor with an operating range of -55°C to 125°C. This device features an 11-bit resolution and communicates via I2C/SMBus. The AT30TS750-SS8-T is housed in an 8-SOIC package and supports surface mount installation. Key functionalities include one-shot conversion, an output switch, programmable limit, programmable resolution, and shutdown mode, enhancing system efficiency. Accuracy specifications are ±1°C from 0°C to 85°C and ±3°C across the full -40°C to 125°C operating range. This sensor is suitable for applications in consumer electronics, industrial automation, and medical devices. It operates from a 2.7V to 5.5V supply. The component is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | One-Shot, Output Switch, Programmable Limit, Programmable Resolution, Shutdown Mode |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | I2C/SMBus |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Supply | 2.7V ~ 5.5V |
| Sensor Type | Digital, Local |
| Resolution | 11 b |
| Supplier Device Package | 8-SOIC |
| Test Condition | 0°C ~ 85°C (-40°C ~ 125°C) |
| Accuracy - Highest (Lowest) | ±1°C (±3°C) |
| Sensing Temperature - Local | -55°C ~ 125°C |
| Sensing Temperature - Remote | - |
