TC7136ARCPL
IC DRVR 7 SEG 3 1/2 DIGIT 40DIPManufacturer: Microchip Technology
Categories: ADCs/DACs - Special Purpose
Quality Control: Learn More
Microchip Technology TC7136ARCPL is a 3 1/2 digit universal analog-to-digital converter (ADC) designed for direct drive of 7-segment displays. This component, housed in a 40-PDIP package, operates with a supply voltage of 9V and features a temperature range of 0°C to 70°C. Its integrated display drivers simplify system design for applications requiring precise measurement and clear digital readout. The TC7136ARCPL is commonly utilized in test and measurement equipment, industrial control systems, and consumer electronics where accurate voltage or current sensing is critical.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 40-DIP (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 9V |
| Supplier Device Package | 40-PDIP |
