TC14433EPG
IC DRVR 7 SEG 3 1/2 DIGIT 24DIPManufacturer: Microchip Technology
Categories: ADCs/DACs - Special Purpose
Quality Control: Learn More
Microchip Technology TC14433EPG is a specialized integrated circuit designed for driving 3 1/2 digit, 7-segment displays. This component, packaged in a 24-PDIP (0.600" width), operates within a supply voltage range of 4.5V to 8V and features a through-hole mounting type. Its operating temperature range is specified from -40°C to 85°C. The TC14433EPG is commonly utilized in applications requiring direct display control, such as instrumentation, industrial control systems, and consumer electronics where clear numerical or alphanumeric readouts are essential. The device facilitates the direct interface with display segments and digit select lines, simplifying the design of display driver circuitry.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-DIP (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 4.5V ~ 8V |
| Supplier Device Package | 24-PDIP |
