MMF017059
STRAIN GAUGEManufacturer: Micro-Measurements (Division of Vishay Precision Group)
Categories: Strain Gauges
Quality Control: Learn More
The Micro-Measurements CEA series linear strain gauge, part number MMF017059, offers a 350 Ohm resistance with a ±0.3% tolerance. This device features an active length of 0.125 inches (3.18mm) and an active width of 0.100 inches (2.54mm). Designed for robust performance, it boasts a strain range of ±5% and operates across a wide temperature spectrum from -75°C to 175°C (-100°F to 350°F). The overall pattern length is 0.275 inches (6.99mm), with an overall length of 0.38 inches (9.7mm) and an overall width of 0.19 inches (4.8mm). This component is utilized in critical applications within the aerospace, automotive, and structural testing industries where precise strain measurement is paramount. Supplied in bulk packaging.
Additional Information
Series: CEARoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:&mpn=MMF017059&lbl=1&lbc=000000&q3=1)
Technical Details:
| Packaging | Bulk |
| Operating Temperature | -100 ~ 350°F (-75 ~ 175°C) |
| Length - Overall | 0.38"" (9.7mm) |
| Resistance Tolerance | ±0.3% |
| Width - Overall | 0.19"" (4.8mm) |
| Length - Active | 0.125"" (3.18mm) |
| Strain Range | ±5% |
| Pattern Type | Linear |
| Length - Overall Pattern | 0.275"" (6.99mm) |
| Width - Active | 0.100"" (2.54mm) |
| Width - Overall Pattern | 0.120"" (3.05mm) |
| Resistance | 350 Ohms |
