SMD16HE-TP
DIODE SCHOTTKY 60V 1A SOD123HEManufacturer: Micro Commercial Co
Categories: Single Diodes
Quality Control: Learn More
Micro Commercial Co's SMD16HE-TP is a Schottky diode designed for efficient power rectification. This surface mount component, housed in a SOD-123HE package, offers a reverse voltage rating of 60V and an average rectified current capability of 1A. Key specifications include a maximum forward voltage of 700mV at 2A and a reverse leakage current of 500µA at 60V. The device operates within a temperature range of -55°C to 150°C. This diode's fast switching characteristics make it suitable for applications in power supplies, automotive electronics, and general-purpose rectification. The SMD16HE-TP is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOD-123H |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | SOD-123HE |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 60 V |
| Voltage - Forward (Vf) (Max) @ If | 700 mV @ 2 A |
| Current - Reverse Leakage @ Vr | 500 µA @ 60 V |
