MUR1020-BP
InterfaceManufacturer: Micro Commercial Co
Categories: Single Diodes
Quality Control: Learn More
Diode 200 V 10A Through Hole TO-220AC
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: 14 week(s)Product Status: Not For New DesignsPackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-220-2 |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 35 ns |
| Technology | Standard |
| Capacitance @ Vr, F | 160pF @ 4V, 1MHz |
| Current - Average Rectified (Io) | 10A |
| Supplier Device Package | TO-220AC |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 200 V |
| Voltage - Forward (Vf) (Max) @ If | 1.3 V @ 10 A |
| Current - Reverse Leakage @ Vr | 5 µA @ 200 V |
