MIP50R12E1ATN-BP
IGBT MODULES 1200V 50A, E1AManufacturer: Micro Commercial Co
Categories: IGBT Modules
Quality Control: Learn More
IGBT Module Three Phase Inverter 1200 V 50 A 288 W Chassis Mount E1A
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 9 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Three Phase Bridge Rectifier |
| Configuration | Three Phase Inverter |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.3V @ 15V, 50A |
| NTC Thermistor | Yes |
| Supplier Device Package | E1A |
| IGBT Type | - |
| Current - Collector (Ic) (Max) | 50 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 288 W |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 2.6 nF @ 25 V |
Request a Quote
