MCQ4828A-TP
MOSFET 2N-CH 60V 4.5A 8SOPManufacturer: Micro Commercial Co
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Mosfet Array 60V 4.5A (Ta) 1.25W (Ta) Surface Mount 8-SOP
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Configuration | 2 N-Channel (Dual) |
| Operating Temperature | 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 1.25W (Ta) |
| Drain to Source Voltage (Vdss) | 60V |
| Current - Continuous Drain (Id) @ 25°C | 4.5A (Ta) |
| Input Capacitance (Ciss) (Max) @ Vds | 540pF @ 30V |
| Rds On (Max) @ Id, Vgs | 56mOhm @ 4.5A, 10V |
| Gate Charge (Qg) (Max) @ Vgs | 10.5nC @ 10V |
| FET Feature | - |
| Vgs(th) (Max) @ Id | 3V @ 250µA |
| Supplier Device Package | 8-SOP |
