MUR2010CT-BP
DIODE ARRAY GP 100V 20A TO220ABManufacturer: Micro Commercial Co
Categories: Diode Arrays
Quality Control: Learn More
Diode Array 1 Pair Common Cathode 100 V 20A Through Hole TO-220-3
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-220-3 |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 35 ns |
| Technology | Standard |
| Diode Configuration | 1 Pair Common Cathode |
| Current - Average Rectified (Io) (per Diode) | 20A |
| Supplier Device Package | TO-220AB |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 975 mV @ 10 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 100 V |
