MLX91377GGO-ADB-081-TU
TRIAXIS POSITION SENSORLINEAR HAManufacturer: Melexis Technologies NV
Categories: Linear, Compass (ICs)
Quality Control: Learn More
Melexis Technologies NV MLX91377GGO-ADB-081-TU is a single-axis Hall Effect position sensor. This AEC-Q100 qualified component utilizes Hall effect technology to provide linear position sensing with a 16-bit resolution. The device operates from a 4.5V to 5.5V supply, drawing a maximum of 13.5mA. It features programmable settings and temperature compensation for enhanced performance. The output is delivered via an SPC interface, with a maximum output current of 35mA. This surface mount device is housed in a 16-TSSOP package, measuring 16-TSSOP (0.173", 4.40mm Width). The MLX91377GGO-ADB-081-TU is designed for operation across a wide temperature range of -40°C to 160°C. Its robust design and automotive grade qualification make it suitable for applications in the automotive industry, including advanced driver-assistance systems (ADAS) and electric power steering (EPS).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 60 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Programmable, Temperature Compensated |
| Packaging | Tube |
| Package / Case | 16-TSSOP (0.173"", 4.40mm Width) |
| Output Type | SPC |
| Mounting Type | Surface Mount |
| Axis | Single |
| Operating Temperature | -40°C ~ 160°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Bandwidth | - |
| Technology | Hall Effect |
| Resolution | 16 b |
| Sensing Range | - |
| Current - Output (Max) | 35mA |
| Current - Supply (Max) | 13.5mA |
| Supplier Device Package | 16-TSSOP |
| Grade | Automotive |
| Qualification | AEC-Q100 |
