MLX91377GGO-ADB-011-SP
TRIAXIS POSITION SENSORLINEAR HAManufacturer: Melexis Technologies NV
Categories: Linear, Compass (ICs)
Quality Control: Learn More
Melexis Technologies NV MLX91377GGO-ADB-011-SP is a single-axis Hall effect linear position sensor. This device employs advanced Hall plate technology for precise magnetic field measurement, translating linear displacement into an analog voltage output. It features integrated temperature compensation and programmability, enabling customization for specific application requirements. The MLX91377GGO-ADB-011-SP is AEC-Q100 qualified, suitable for demanding automotive applications, and operates within a voltage supply range of 4.5V to 5.5V. With a maximum output current of 35mA and a supply current of 13.5mA, it offers efficient operation. The sensor is packaged in a 16-TSSOP (0.173", 4.40mm Width) for surface mounting and operates across an extended temperature range of -40°C to 160°C. This component is designed for applications requiring accurate linear position feedback in automotive systems and other industrial environments.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 60 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Programmable, Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 16-TSSOP (0.173"", 4.40mm Width) |
| Output Type | Analog Voltage |
| Mounting Type | Surface Mount |
| Axis | Single |
| Operating Temperature | -40°C ~ 160°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Bandwidth | - |
| Technology | Hall Effect |
| Resolution | 16 b |
| Sensing Range | - |
| Current - Output (Max) | 35mA |
| Current - Supply (Max) | 13.5mA |
| Supplier Device Package | 16-TSSOP |
| Grade | Automotive |
| Qualification | AEC-Q100 |
