MLX91221KDF-ABF-020-TU
SENSOR CURRENT HALL 20A 16SOICManufacturer: Melexis Technologies NV
Categories: Current Sensors
Quality Control: Learn More
Current Sensor 20A 1 Channel Hall Effect Bidirectional 16-SOIC (0.295"", 7.50mm Width)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SOIC (0.295"", 7.50mm Width) |
| Polarization | Bidirectional |
| Sensitivity | 62.5mV/A |
| Mounting Type | Surface Mount |
| Output | Fixed, Voltage |
| Frequency | DC ~ 300kHz |
| Accuracy | - |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 3.135V ~ 3.465V |
| Response Time | 2µs |
| Sensor Type | Hall Effect |
| Linearity | ±0.6% |
| For Measuring | AC/DC |
| Current - Supply (Max) | 26mA |
| Current - Sensing | 20A |
| Number of Channels | 1 |
