PWM-120-12KN
120W PWM OUTPUT KNX LED DRIVER OManufacturer: MEAN WELL USA Inc.
Categories: LED Drivers
Quality Control: Learn More
10A 12V Constant Voltage LED Driver AC DC Converter Topology 1 Output
Additional Information
Series: PWM-120-KN (120W)RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | OCP, OTP, OVP, SCP |
| Packaging | Bulk |
| Size / Dimension | 7.52"" L x 2.48"" W x 1.48"" H (191.0mm x 63.0mm x 37.5mm) |
| Voltage - Output | 12V |
| Type | Constant Voltage |
| Operating Temperature | -40°C ~ 90°C |
| Termination Style | Wire Leads |
| Voltage - Input (Max) | 305VAC |
| Approval Agency | CB, CCC, CE, EAC, ENEC |
| Ratings | - |
| Efficiency | 88% |
| Topology | AC DC Converter |
| Current - Output (Max) | 10A |
| Dimming | PWM |
| Voltage - Input (Min) | 90VAC |
| Power (Watts) | 120 W |
| Number of Outputs | 1 |
| Voltage - Isolation | 3.75 kV |
| Programmable | Not Verified |
