PLP-45-48
LED DRVR CC AC/DC 36-48V 950MAManufacturer: MEAN WELL USA Inc.
Categories: LED Drivers
Quality Control: Learn More
MEAN WELL USA Inc. PLP-45-48 is a 46W Constant Current LED Driver from the PLP-45 series. This AC/DC converter topology features a single output delivering 950mA with an adjustable output voltage range of 36V to 48V. The driver operates from a universal AC input range of 90VAC to 264VAC, achieving 89% efficiency. Protection features include Over Current Protection (OCP), Over Voltage Protection (OVP), and Short Circuit Protection (SCP). With 3.75 kV isolation, it is suitable for applications requiring robust power conversion. Its compact dimensions of 101.6mm x 50.8mm x 29.6mm and rectangular, 2-position termination style facilitate integration into various lighting systems. Approvals include CB, CCC, CE, TUV, and UR, indicating its suitability for global markets, including industrial and commercial lighting applications. The operating temperature range is -30°C to 70°C.
Additional Information
Series: PLP-45 (45W)RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | OCP, OVP, SCP |
| Packaging | Box |
| Size / Dimension | 4.00"" L x 2.00"" W x 1.17"" H (101.6mm x 50.8mm x 29.6mm) |
| Voltage - Output | 36 ~ 48V |
| Type | Constant Current |
| Operating Temperature | -30°C ~ 70°C |
| Termination Style | Rectangular, 2 Position |
| Voltage - Input (Max) | 264VAC |
| Approval Agency | CB, CCC, CE, TUV, UR |
| Ratings | - |
| Efficiency | 89% |
| Topology | AC DC Converter |
| Current - Output (Max) | 950mA |
| Dimming | - |
| Voltage - Input (Min) | 90VAC |
| Power (Watts) | 46 W |
| Number of Outputs | 1 |
| Voltage - Isolation | 3.75 kV |
| Programmable | Not Verified |
