IDPC-65A-700
LED DRVR CC AC/DC 69-93V 700MAManufacturer: MEAN WELL USA Inc.
Categories: LED Drivers
Quality Control: Learn More
MEAN WELL USA Inc. IDPC-65A-700 is a 65W Constant Current LED Driver from the IDPC-65 series. This AC/DC converter topology offers a single output with a maximum current of 700mA and an adjustable output voltage range of 69V to 93V. Designed for efficient operation, it achieves up to 89% efficiency and features SCP protection. The driver supports both Analog and PWM dimming methods. Its input voltage range is 180VAC to 295VAC, with 3.75 kV isolation voltage. The unit is housed in a 130.0mm x 67.5mm x 20.5mm enclosure with terminal block terminations. Approvals include CB, CE, CCC, cURus, and ENEC. This component is suitable for applications in general lighting and architectural lighting.
Additional Information
Series: IDPC-65 (65W)RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | SCP |
| Packaging | Box |
| Size / Dimension | 5.12"" L x 2.66"" W x 0.81"" H (130.0mm x 67.5mm x 20.5mm) |
| Voltage - Output | 69 ~ 93V |
| Type | Constant Current |
| Operating Temperature | -20°C ~ 40°C |
| Termination Style | Terminal Block |
| Voltage - Input (Max) | 295VAC |
| Approval Agency | CB, CE, CCC, cURus, ENEC |
| Ratings | - |
| Efficiency | 89% |
| Topology | AC DC Converter |
| Current - Output (Max) | 700mA |
| Dimming | Analog, PWM |
| Voltage - Input (Min) | 180VAC |
| Power (Watts) | 65 W |
| Number of Outputs | 1 |
| Voltage - Isolation | 3.75 kV |
| Programmable | Not Verified |
